Switch action Characteristics

The defining characteristics of operation Operating Parameter Abbreviation Units Value
Free Position FP mm 12.1±0.2
Operating Position OP mm 11.5±0.5
Releasing Position RP mm 11.7±0.5
Total travel Position TTP mm 10.5±0.3
Operating Force OF N 1.0~3.5
Releasing Force RF N
Total travel Force TTF N
Pre Travel PT mm 0.3~1.0
Over Travel OT mm 0.2Min
Movement Differential MD mm 0.4Max

Switch technical Characteristics

ITEM

technical parameter

Value

1

Electrical Rating 52A 250VAC

2

Contact  Resistance ≤50mΩInitial value

3

Insulation Resistance ≥100MΩ500VDC

4

Dielectric Voltage between non-connected terminals 500V/0.5mA/60S
between terminals and the metal frame 1500V/0.5mA/60S

5

Electrical Life ≥10000 cycles

6

Mechanical Life ≥100000 cycles

7

Operating Temperature -25~125℃

8

Operating Frequency electrical:15 cycles
Mechanical:60 cycles

9

Vibration Proof Vibration Frequency:10~55HZ;
Amplitude:1.5mm;
Three directions:1H

10

Solder Ability: More than 80% of immersed part shall be covered with solder Soldering Temperature:235±5℃
Immersing Time:2~3S

11

Solder Heat Resistance Dip Soldering:260±5℃ 5±1S
Manual Soldering:300±5℃ 2~3S

12

Safety Approvals UL,CSA,VDE,ENEC,CE

13

Test Conditions Ambient Temperature:20±5℃
Relative Humidity:65±5%RH
Air Pressure:86~106KPa

Switch application: widely used in various household appliances, electronic equipment, automation equipment, communication equipment, automotive electronics, power tools and other fields.


Product detail pictures:
